Stainless steel probe Thermocouple RTD sensor k type with K E J B R S type thermocouple

Brand Name : GME

Certification : CE

Place of Origin : China

MOQ : 50pcs

Payment Terms : T/T, Western Union, MoneyGram, L/C

Supply Ability : 100000 pcs per Month

Delivery Time : 7~10 working days

Packaging Details : cartons， pallet

Power Source : Electric

Temperature range : -200~650℃

Voltage : 12-480V

Probe material : Stainless Steel or Nickel

Style : K, J, S

Pairs quantity of element : Simplex/duplex

Heating Element : Nichrome Resistance

Mounting : Thread/flange/none

Function : Temperature sensor

Feature : Economical

Types of terminal box : Anti-spray/water-proof

Connection : Thread

Contact Now

Stainless steel probe Thermocouple RTD sensor k type with K E J B R S type thermocouple

Description:

1) Thermocouples are a widely used type of temperature sensorfor measurement and control,and can also convert a temperature gradient into electricity. Commercial thermocouples are inexpensive,interchangeable, are supplied with standard connectors, and can measure a wide range of temperatures. In contrast to most other methods of temperature measurement, thermocouples are self powered and require no external form of excitation.

2) A thermocouple is a temperature-measuring device consisting of two dissimilar conductors that contact each other at one or more spots. It produces a voltage when the temperature of one of the spots differs from the reference temperature at other parts of the circuit.

Specification:

1) Type: K/E/J/R/S/B thermocouple
2)Temperature range:1500/1600/1800
3) Stainless Steel / Ceramic tube
4) Diameter:16mm
5) Length:600mm

Special thermocouple is made of noble metal,( platium in high purity as cathode, Platium and Rhodium alloy as positive pole), corundum as external tube, which is used to measure as high as 1800 like powder metallurgy,fritting furnace,vacuum furnace, matallurgy furnace and calcination of fire-proof materials, proclein, ceramics.

Conductir material	Type	Graduation	Spec. of protection tube(mm)				Use temperature
Conductir material	Type	Graduation	Total Lenght	Length in fluid	external diameter of ceramic tube	Material of protection tube	Use temperature
PtRh10-Pt	WRP	S	300 350 400 450 550 650 900 1150 1250	150 200 250 300 400 500 750 1000 1100	φ16 φ25	High Al content tube	0-1300
PtRh30-Ptrh6	WRR	B			φ16 φ25	Corundum tube	0-1600
PtRh13-pT	WRQ	R			φ16 φ20	High Al content tube	0-1200
Mini PtRh10-Pt	WRP-100	S	252	252	φ7	High Al content tube	0-1200

Stainless steel probe Thermocouple RTD sensor k type with K E J B R S type thermocouple

Application:

Thermocouples are widely used in below areas:
Diesel engine
Industrial furnace
Steel industry
Kiln
Petrochmeical industry
Gas trubine exhaust

Thermocouples are widely used in science and industryapplications include temperature measurement for kilns, gas turbine exhaust, diesel engines, and other industrial processes.Thermocouples are also used in homes, offices and businesses as the temperature sensors in thermostats,and also as flame sensors in safety devices for gas-powered major appliances.
Stainless steel probe Thermocouple RTD sensor k type with K E J B R S type thermocouple

Payment Terms and Shipping:

International express for sample or small orders. Air transportation and sea transportation for big orders.
